Maximum Output Power 1 x 4000W (1Ω), 1 x 3000W (2Ω), 1 x 1500W (4Ω)
Continuous power output (RMS)
• 1 x 2000W (50Hz/1Ω ≤ 1%THD)
• 1 x 1500W (50Hz/2Ω ≤ 1%THD)
• 1 x 750W (20Hz - 240Hz/4Ω ≤ 1%THD)
Load impedance capability 1 - 8Ω
Frequency response 10 - 240 Hz
Distortion < 0.3 %
S/N ratio > 85 dB
Bass Boost 40 - 120Hz
0, 6, 9, 12 dB via remote control
LPF 40 - 240Hz (-24dB/Oct)
Subsonic Filter (HPF) 20Hz (-24dB/Oct)
MOSFET output section Ja
Sync Control Ja
RCA terminals Yes (input/output)
Speaker Terminals Block-type
High Voltage Input 200mV - 6.5 V
Input level control 400 mV - 6.5 V
High performance balanced isolator circuit Ja
Max. current consumption (A/4Ω) 67A
Chassis size (W x H x D) 586 x 65 x 282 mm
